SN74CBT16209A

Features: 5-W Switch Connection Between Two PortsTTL-Compatible Input LevelsPackage Options Include Plastic Thin Shrink Small-Outline (DGG), Thin Very Small-Outline (DGV), 300-mil Shrink Small-Outline (DL), and 380-mil Fine-Pitch Ceramic Flat (WD) PackagesPinoutSpecificationsSupply voltage range, ...

product image

SN74CBT16209A Picture
See larger image
SeekIC No. : 004498675 Detail

SN74CBT16209A: Features: 5-W Switch Connection Between Two PortsTTL-Compatible Input LevelsPackage Options Include Plastic Thin Shrink Small-Outline (DGG), Thin Very Small-Outline (DGV), 300-mil Shrink Small-Outli...

SN74CBT16209A Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SN74CBT16209A
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

5-W Switch Connection Between Two Ports
TTL-Compatible Input Levels
Package Options Include Plastic Thin Shrink Small-Outline (DGG), Thin Very Small-Outline (DGV), 300-mil Shrink Small-Outline (DL), and 380-mil Fine-Pitch Ceramic Flat (WD) Packages


Pinout

Connection Diagram


Specifications

Supply voltage range, VCC   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .... . . . . .0.5 V to 7 V
Input voltage range, VI (see Note 1)   . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .. . .0.5 V to 7 V
Continuous channel current  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . . . . . 128 mA
Input clamp current, IIK (VI < 0)   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . . . . . . 50 mA
Package thermal impedance, JA (see Note 2): DGG package . . . . . . . . . . . . . . . . . . . . . .89°C/W
DGV package  . . . . . . . . . . . . . . . . . . . . . . . ...................................................... . . . . . . . . 93°C/W
DL package  . . . . . . . . . . . . . . .............................................................................  . . . . . . .94°C/W
Storage temperature range, Tstg  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 65°C to 150°C


Description

The SN54CBT16209 and SN74CBT16209A devices provide 18 bits of high-speed TTL-compatible bus switching or exchanging. The low on-state resistance of the switches allows connections to be made with minimal propagation  delay.

The SN74CBT16209A devices operate as an 18-bit bus switch or a 9-bit bus exchanger, which provides data exchanging between the four signal ports via the data-select  (S0, S1, S2) terminals.

The SN54CBT16209 is characterized for operation over the full military temperature range of 55°C to 125°C. The SN74CBT16209A is characterized for operation from 40°C to 85°C.
