SN74CBT16210

Pinout




Specifications

Supply voltage range, VCC   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 V to 7 V
Input voltage range, VI (see Note 1)  . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 V to 7 V
Continuous channel current   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . . . 128 mA
Input clamp current, IIK (VI < 0)   . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . 50 mA
Package thermal impedance, JA (see Note 2): DGG package  . . . . . . . . . . .89°C/W
DGV package  93°C/W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . . . 93°C/W
DL package  94°C/W . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . .. .. .  . . . 94°C/W
Storage temperature range, Tstg  . . . . . . . . . . . . . . . . . . . ... . . . .65°C to 150°C


Description

The SN74CBT16210 provides 20 bits of high-speed TTL-compatible bus switching. The low on-state resistance of the switch allows connections to be made with minimal propagation delay.

The SN74CBT16210 device is organized as a dual 10-bit bus switch with separate output-enable (OE) inputs. It can be used as two 10-bit bus switches or as one 20-bit bus switch. When OE is low, the associated 10-bit bus switch is on and port A is connected to port B. When OE is high, the switch is open, and a high-impedance state exists between the ports.

The SN74CBT16210 is characterized for operation from 40°C to 85°C.
