Part Number: SP34063A
Description: The SP34063A is a monolithic switching regulator control circuit containing the primary functions...
- Table of contents:
SP34063A
-
Suppliers
DataSheet
General Description
SP34063A General Description
The SP34063A is a monolithic switching regulator control circuit containing the primary functions required for DC-DC converters. This device consists of an internal temperature compensated reference, voltage comparator, controlled duty cycle oscillator with active current limit circuit, driver and high current output switch. This device was specifically designed to be used in buck, boost, and Voltage-Inverting applications with a minimum number of external components. The SP34063A is available in 8 pin NSOIC package.
SP34063A Features
Supply Voltage: 3V - 36V
Current Limiting
Output Switch Current to 1.5A
Adjustable Output Voltage
Operation frequency up to 110KHz
Low Quiescent Current
Precision 2% Reference
Available in 8 pin NSOIC Package
Current Limiting
Output Switch Current to 1.5A
Adjustable Output Voltage
Operation frequency up to 110KHz
Low Quiescent Current
Precision 2% Reference
Available in 8 pin NSOIC Package
SP34063A Typical Application
Battery Charger Circuit
NICs/Switches/Hubs
ADSL Modems
Negative Voltage Power Supply
NICs/Switches/Hubs
ADSL Modems
Negative Voltage Power Supply
SP34063A Connection Diagram
