SP4438

The SP4438 device is a low noise, high voltage output DC-AC inverter designed to drive electroluminescent lamps to backlight liquid crystal display and keypads used in cellular phones, cordless phones, 2-way radios, and other wireless communication products. The output waveform of the device is ideal for cell phone applications requiring low acoustic noise performance. One external resistor is used to set the internal oscillator frequency and one inductor is required to generate the high voltage AC output to drive an EL lamp up to 3 square inches in size. The operates from a +3.0V battery source and has a low power standby mode that draws less than 1µA, making it ideal for low-power cellular applications. All input pins are ESD protected with internal diodes to V_DD and V_SS. The SP4438 is offered in a space-saving 8-pin MSOP package.
