MFG:ST Package Cooled:06/07+ D/C:SOP-8P
MFG: ST
Package Cooled: 06/07+
D/C: SOP-8P
Description: The fundamental of SP6013A synchronous rectifier (SR) driver IC is based on our U.S. patented methods ...
The fundamental of SP6013A synchronous rectifier (SR) driver IC is based on our U.S. patented methods that utilize the principle of "prediction" logic circuit. The IC deliberates previous cycle timing to control the SR in present cycle by "predictive" algorithm that makes adjustments to the turn-off time, in order to achieve maximum efficiency and avoid cross-conduction at the same time. It also maintains the MOSFET's body diode conduction at minimum level. The SP6013A is capable to adapt in almost all existing flyback converters with few adjustments considered necessary.
|
Symbol |
Parameter |
Value |
Unit |
|
Vdd SYNC IOUT PD TJ TSTG TLEAD |
DC Supply Voltage SYNC Voltage Peak Source Current (Pulsed) Peak Sink Current (Pulsed) Power Dissipation @ TA=85 (*) Operating Junction Temperature Range Storage Temperature Range Lead Soldering Temperature for 5 sec. |
7 7 3 3 0.25 -40 to 150 -40 to 150 260 |
V V A A W |
SP6013A
