SR5511(B)

Features: • Red colored diffusion lens type• 5mm(T-13/4) all plastic mold type• Available on tape and reelPinoutSpecifications Characteristic Symbol Ratings Unit Power Dissipation PD 23 mW Forward Current IF 10 mA *1Peak Forward Current IFP 50 mA Reve...

product image

SR5511(B) Picture
SeekIC No. : 004502135 Detail

SR5511(B): Features: • Red colored diffusion lens type• 5mm(T-13/4) all plastic mold type• Available on tape and reelPinoutSpecifications Characteristic Symbol Ratings Unit Power D...

floor Price/Ceiling Price

Part Number:
SR5511(B)
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/24

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Red colored diffusion lens type
• 5mm(T-13/4) all plastic mold type
• Available on tape and reel





Pinout






Specifications

Characteristic Symbol Ratings Unit
Power Dissipation PD 23 mW
Forward Current IF 10 mA
*1Peak Forward Current IFP 50 mA
Reverse Voltage VR 4 V
Operating Temperature Topr -25∼85
Storage Temperature Tstg -30∼100
*2Soldering Temperature Tsol 260 for 5 seconds

*1.Duty ratio = 1/16, Pulse width = 0.1ms
*2. Keep the distance more than 2.0mm from PCB to the bottom of LED package





Description

SR5511(B) has been used ,as a lense package, for a sign board and many electric appliances. * High brightness for the colorful sign boards * Low power consumption lamps can save more energy * Lensed package allow user to make more eradiating power
