ST10F163

Ambient temperature under bias (T_A): . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to +70 °C
Storage temperature (T_ST): . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . 65 to +150 °C
Voltage on VDD pins with respect to ground (V_SS): . . . . . . . . . . . . . . . 0.5 to +6.5 V
Voltage on any pin with respect to ground (V_SS):  . . . . . . . . . .  . .0.5 to V_DD +0.5 V
Input current on any pin during overload condition:  . . . . . . . . . . . . . .10 to +10 mA
Absolute sum of all input currents during overload condition: . . . . . . .. . . . . .|100 mA|
Power dissipation: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . 1.5 W
Note Stresses above those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not guaranteed. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. During overload conditions (V_IN>V_DD or V_IN <V_SS) the

The ST10F163 is a Flash derivative of the STMicroelectronics ST10 family of 16-bit microcontrollers. It combines high CPU performance (up to 12.5 million instructions per second) with high peripheral functionality and enhanced IO-capabilities. 128KBytes of an electrically erasable and re-programmable Flash EPROM is provided on-chip.
