ST10F167

Ambient temperature under bias (T_A): ST10F167............................................ 40to +85 °C
Storage temperature (T_ST).......................................................................... 65 to +150 °C
Voltage on VDD pins with respect to ground (V_SS)........................................... 0.5 to +6.5 V
Voltage on any pin with respect to ground (V_SS) ....................................... 0.3to V_DD +0.3 V
Input current on any pin during overload condition.......................................... 10 to +10 mA
Absolute sum of all input currents during overload condition...................................... |100 mA|
Power dissipation............................................................................................................ 1.5 W
Note: Stresses above those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not guaranteed. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. During overload conditions (V_IN>V_DD or V_IN<V_SS) the voltage on pins with respect to ground (VSS) must not exceed the values defined by the Absolute Maximum Ratings.

The ST10F167 is a flash derivative of the SGS-THOMSON ST10 family of full featured single-chip CMOS microcontrollers. It combines high CPU performance with high peripheral functionality and enhanced IO-capabilities. It also provides on-chip high-speed RAM and clock generation via PLL.
