ST5870

Features: • Lensed for high sensitivity• 5mm(T-13/4) all plastic mold type• High reliability and stable characteristics• Visible light cut-off type• With base terminalPinoutSpecifications Characteristic Symbol Ratings Unit Collector-Emitter Voltage VCEO ...

product image

ST5870 Picture
See larger image
SeekIC No. : 004506564 Detail

ST5870: Features: • Lensed for high sensitivity• 5mm(T-13/4) all plastic mold type• High reliability and stable characteristics• Visible light cut-off type• With base terminalP...

ST5870 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
ST5870
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Lensed for high sensitivity
• 5mm(T-13/4) all plastic mold type
• High reliability and stable characteristics
• Visible light cut-off type
• With base terminal




Pinout






Specifications

Characteristic Symbol Ratings
Unit
Collector-Emitter Voltage VCEO
30
V
Emitter-Collector Voltage VECO
6
V
Collector-Base Voltage VCBO
30
V
Emitter-Base Voltage VEBO
6
V
Collector Current IC
20
mA
CollectorPower Dissipation PD
75
mW
Operating Temperature Topr
-25 to +85
··
Storage Temperature Tstg
-30 to +100
··
*1Soldering Temperature Tsol
260·· for 5 seconds
*1. Keep the distance more than 2.0mm from PCB to the bottom of LED package




Description

This device ST5870 is used as an optical counter and detecter. This high sensitivity NPN silicon photo transistor converts light energy into electrical signal. We supply photo transistors with a quick response and an accurate detection capability.
