ST72361

Memories
16K to 60K High Density Flash (HDFlash) or ROM with read-out protection capability. In- Application Programming and In-Circuit Programming for HDFlash devices
1.5 to 2K RAM
HDFlash endurance: 100 cycles, data retention:40 years at 85°C
Clock, Reset and Supply Management
Low power crystal/ceramic resonator oscillators and bypass for external clock
PLL for 2x frequency multiplication
Five Power Saving Modes: Halt, Auto Wake Up From Halt, Active-Halt, Wait and Slow
Interrupt Management
Nested interrupt controller
14 interrupt vectors plus TRAP and RESET
TLI top level interrupt (on 64-pin devices)
Up to 21 external interrupt lines (on 4 vectors)
Up to 48 I/O Ports
Up to 48 multifunctional bidirectional I/O lines
Up to 36 alternate function lines
Up to 6 high sink outputs
5 Timers
16-bit Timer with: 2 input captures, 2 output compares, external clock input, PWM and pulse generator modes
8-bit Timer with: 1 or 2 input captures, 1 or 2 output compares, PWM and pulse generator modes
8-bit PWM Auto-Reload Timer with: 1 or 2 input captures, 2 or 4 independent PWM output channels, output compare and time base interrupt,external clock with event detector
Main Clock Controller with: Real time base and Clock output
Window watchdog timer
Up to 3 Communications Interfaces
SPI synchronous serial interface
Master/slave LINSCI™ asynchronous serial interface
Master-only LINSCI™ asynchronous serial interface
Analog peripheral (low current coupling)
10-bit A/D Converter with up to 16 inputs
Up to 9 robust ports (low current coupling)
Instruction Set
8-bit data manipulation
63 basic instructions
17 main addressing modes
8 x 8 unsigned multiply instruction
Development Tools
Full hardware/software development package
