STK14CA8

Features:

•  25ns, 35ns and 45ns Access Times
•  "Hands-off" Automatic STORE on Power Down
    with only a small capacitor
•  STORE to QuantumTrap™ Nonvolatile
    Elements is Initiated by Software , device pin
    or AutoStore™ on Power Down
•  RECALL to SRAM Initiated by Software or  Power Up
•  Unlimited READ, WRITE and RECALL Cycles
•  5mA Typical ICC at 200ns Cycle Time
•  1,000,000 STORE Cycles to QuantumTrap™
•  100-Year Data Retention to QuantumTrap™
•  Single 3V +20%, -10% Operation
•  Commercial and Industrial Temperatures
•  SOIC, SSOP and DIP Packages
•  RoHS Compliance


Pinout




Specifications

Power Supply Voltage ............................................-0.5V to +4.1V
Voltage on Input Relative to VSS ................-0.5V to (VCC + 0.5V)
Voltage on Outputs .................................. -0.5V to (VCC + 0.5V)
Temperature under Bias .................................55°C to 125°C
Junction Temperature......................................55°C to 140°C
Storage Temperature .......................................65°C to 150°C
Power Dissipation.....................................................................1W
DC Output Current (1 output at a time, 1s duration)............15mA



Description

The Simtek STK14CA8 is a fast static RAM with a  nonvolatile element in each memory cell. The  embedded nonvolatile elements incorporate  Simtek's QuantumTrapTM  technology producing the  world's most reliable nonvolatile memory. The  SRAM provides unlimited read and write cycles,  while independent, nonvolatile data resides in the  highly reliable  QuantumTrapTM cell. Data transfers  from the SRAM to the nonvolatile elements (the  STORE operation) takes place automatically at  power down. On power up, data is restored to the  SRAM (the RECALL operation) from the nonvolatile  memory. Both the STORE and RECALL operations  are also available under software control.
