Part Number: STM915-16
Description: The STM915-16 is a linear power module designed for 12.5 V applications in GSM Cellular Radio Systems. The STM915-16 uses...
- Table of contents:
STM915-16
-
Suppliers
DataSheet
General Description
STM915-16 General Description
The STM915-16 is a linear power module designed for 12.5 V applications in GSM Cellular Radio Systems. The STM915-16 uses gold metallized transistors with diffused emitter ballast resistors for high linearity Class AB operation.
STM915-16 Maximum Ratings
| Symbol | Parameter | Value | Unit |
| VS2, VS4 | DC Supply Voltage (RF applied/No RF applied) | 15.6/30.0 | Vdc |
| VS1, VS3 | DC Supply Voltage | 8.5 | Vdc |
| VCONTROL | DC Control Voltage | 4.5 | Vdc |
| PIN | RF Input Power (POUT 17 W) | 3.0 | mW |
| POUT1 | RF Output Power (VS2,VS4 = 12.5 V) | 20 | W |
| TSTG | Storage Temperature | - 30 to + 100 | oC |
| TC | Operating Case Temperature | - 30 to + 100 | oC |
Repetition rate = 4.6 msec.
STM915-16 Features
LINEAR POWER AMPLIFIER
890-915 MHz
12.5 VOLTS
INPUT/OUTPUT 50 OHMS
POUT = 16 WMIN.
GAIN = 42 dB MIN.
890-915 MHz
12.5 VOLTS
INPUT/OUTPUT 50 OHMS
POUT = 16 WMIN.
GAIN = 42 dB MIN.
