Features: VGA or CIF CMOS sensor supportHardware color processing and JPEG compression of image dataStill image captureTethered video operation over USBSimultaneous video and audio captureUSB USB for PC and MacOS (in development)Flexible external memory optionsSDRAM for lower cost, (8 or 16 bit)FL...
STV0674: Features: VGA or CIF CMOS sensor supportHardware color processing and JPEG compression of image dataStill image captureTethered video operation over USBSimultaneous video and audio captureUSB USB fo...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
VGA or CIF CMOS sensor support
Hardware color processing and JPEG compression of image data
Still image capture
Tethered video operation over USB
Simultaneous video and audio capture
USB
USB for PC and MacOS (in development)
Flexible external memory options
SDRAM for lower cost, (8 or 16 bit)
FLASH for non volatile storage (Data + Code)
Smartmedia Card for removable data storage
EEPROM for code storage
Record simultaneous video and audio direct to memory while untethered
Drivers for PC operating systems Win98, WinME, Win2K and WIn XP.
Description |
Range |
Unit |
Operating Temperature |
0 to 70a |
|
Storage Temperature |
-50 to 150 |
|
The STV0674 is a flexible, scalable digital camera co-processor for use with the range of CMOS imaging sensor products from STMicroelectronics.
The same chipset can be used for a wide range of digital imaging products with unique features and price/performance points.
The STV0674 is designed for use with CIF (352x288) or VGA (640x480) ST CMOS image sensors and provides full exposure control, color processing and mode control for these sensors.
The STV0674 can be used to implement any of the following products:
Low cost USB Webcam Camera - a two-chip solution providing up to 30 frames per second VGA simultaneous video and audio capture.
Dual-Mode Camera - USB webcam and CIF or VGA digital still camera in a single product.
Tri-Mode Camera - USB webcam and digital still camera with the addition of a 'camcorder' mode to allow simultaneous video and audio capture directly to external memory for later upload to the PC.
