See larger image

SeekIC No. : 004509374 Detail

SUR502EF: Features: • Two SRA2204 chips in SOT-563F package• With built-in bias resistorsPinoutSpecifications Characteristic Symbol Ratings Unit Output voltage VO -50 ...

SUR502EF Data Sheet

Get Latest Price

Part Number:: SUR502EF
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

SUR501J evaluate
Features: • Both SRC1207 and SRA2207 Chips in SOT-363 package• With built-in bias resi...
SUR503EF evaluate
Features: • Two SRC1206 chips in SOT-563F package• With built-in bias resistorsPinoutS...
SUR506EF evaluate
Features: • Two SRA2205 chips in SOT-563F package• With built-in bias resistorsPinoutS...

Product Details

Description

Features:

• Two SRA2204 chips in SOT-563F package
• With built-in bias resistors

Pinout

Specifications

Characteristic	Symbol	Ratings	Unit
Output voltage	V_O	-50	V
Input voltage	V_I	-40	V
Output current	I_O	-100	mA
Power dissipation	P_D	100	mW
Junction temperature	T_j	150	°C
Storage temperature	T_stg	-55~150	°C

Description

AUK offers a variable type of Bias Resistor Transistors , equipped with Pull-down resistors and integrated biasing to assist the designer in reducing parts count and board space requirements.

• Digital transistor of the SUR502EF
