SX28AC

Features: • Compact instruction set• All instructions are single cycle except branch• Eight-level push/pop hardware stack for subroutine linkage• Fast table lookup capability through run-time readable code (IREAD instruction)• Totally predictable program execution flo...

product image

SX28AC Picture
See larger image
SeekIC No. : 004509731 Detail

SX28AC: Features: • Compact instruction set• All instructions are single cycle except branch• Eight-level push/pop hardware stack for subroutine linkage• Fast table lookup capability...

SX28AC Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SX28AC
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Compact instruction set
• All instructions are single cycle except branch
• Eight-level push/pop hardware stack for subroutine linkage
• Fast table lookup capability through run-time readable code (IREAD instruction)
• Totally predictable program execution flow for hard real-time applications


Pinout

Connection Diagram




Specifications

Ambient temperature under bias -40°C to +85°C
Storage temperature -65°C to +150°C
Voltage on Vdd with respect to Vss 0 V to +7.0V
Voltage on OSC1 with respect to Vss 0 V to +13.5V
Voltage on MCLR with respect to Vss 0 V to +13.5V
Voltage on all other pins with respect to Vss -0.6 V to (Vdd + 0.6V)V
Total power dissipation 700 mW
Max. current out of Vss pin 130 mA
Max. current into Vdd pin 130 mA
Max. DC current into an input pin (with internal protection diode forward biased) ±500 mA
Max. allowable sink current per I/O pin 45 mA
Max. allowable source current per I/O pin 45 mA
