SY10H350

NOTE:
1. Permanent device damage may occur if ABSOLUTE MAXIMUM RATINGS re exceeded. This is a stress rating only and functional operation is not mplied at conditions other than those detailed in the operational sections f this data sheet. Exposure to ABSOLUTE MAXIMUM RATlNG conditions or extended periods may affect device reliability.

The SY10H350 consists of 4 translators with differential nputs and TTL outputs. The 3-state outputs can be isabled by applying a HIGH TTL logic level on the ommon OE input.

The SY10H350 is designed to be used primarily in ystems incorporating both ECL and TTL logic operating ff a common power supply. The separate V_CC power ins are not connected internally and thus isolate the oisy TTL V_CC runs from the relatively quiet ECL V_CC uns on the printed circuit board. The differential inputs llow the SY10H350 to be used as an inverting or noninverting ranslator, or a differential line receiver. The H350 can lso drive CMOS with the addition of a pullup resistor.
