Product Details

Description



Features:

` TA6009FM operates from 2.7 to 5.5 V DC single power supply voltage.
` Signal from the shock sensor is amplified according to setting gain, and is detected through the internal window comparator.
` TA6009FM incorporates 1-ch shock detecting circuitry.
` Input terminal of sensor signal is designed high impedance. Differential input impedance = 100 M (typ.)
` LPF (Low Pass Filter) circuitry is incorporated. Cut-off frequency of LPF = 7 kHz
` Sensitivity of shock detection can be adjusted by external devices.
` Small package SON10-P-0303-0.50 (0.5 mm pitch)




Pinout

  Connection Diagram


Specifications

Characteristics
Symbol
Rating
Unit
Power supply voltage
VCC
7
V
Power dissipation
PD
150
mW
Storage temperature
Tstg
-55 to 150
