Part Number: TLP3502
MFG: TOS
Description: The TOSHIBA TLP3502 consists of a photo−triac optically coupled to a gallium arsenide infrared e...
- Table of contents:
TLP3502
-
Suppliers
DataSheet
General Description
TLP3502 General Description
The TOSHIBA TLP3502 consists of a photo−triac optically coupled to a gallium arsenide infrared emitting diode in a 8 lead plastic DIP package.
TLP3502 Maximum Ratings
|
Characteristic |
Symbol |
Rating |
Unit | ||
|
LED |
Forward current |
IF |
50 |
mA | |
|
Forward current derating (Ta 53°C) |
IF /°C |
-0.7 |
mA /°C | ||
|
Peak forward current (100 s pulse, 100 pps) |
IFP |
1 |
A | ||
|
Reverse voltage |
VR |
5 |
V | ||
|
Junction temperature |
Tj |
125 |
°C | ||
|
Detector |
Off-state output terminal voltage |
VDRM |
400 |
V | |
|
On-state RMS current |
Ta=40°C |
IT(RMS) |
0.5 |
A | |
|
Ta=60°C |
0.35 | ||||
|
On-state current derating (Ta 40°C) |
IT / °C |
-7.2 |
mA / °C | ||
|
Peak on-state current (100s pluse, 120pps) |
ITP |
2 |
A | ||
|
Peak nonrepetitive surge current(50Hz,peak) |
ITSM |
5 |
A | ||
|
Junction temperature |
Tj |
110 |
°C | ||
|
Storage temperature range |
Tstg |
-40~125 |
°C | ||
|
Operating temperature range |
Topr |
-20~80 |
°C | ||
|
Lead soldering temperature (10s) |
Tsol |
260 |
°C | ||
|
Isolation voltage (AC, 1 min., R.H. 60%) (Note) |
BVS |
2500 |
Vrms | ||
(Note) Device considered a two terminal: LED side pins shorted together and detector side pins shorted together.
TLP3502 Features
Peak off−state voltage: 400V(min.)
Trigger LED current: 10mA(max.)
On−state current: 0.5Arms(max.)
Isolation voltage: 2500Vrms(min.)
UL recognized: UL1577, file no. E67349
Trigger LED Current
TLP3502 Connection Diagram
