TND512MD

Features: • 3-phase high side driver.• Monolithic structure.• Allows simplified configuration of driver circuit.• Withstand voltage of 600V is assured.• Fully compatible input to LSTTL/CMOS.• High-speed switching.• Output current : 170mA Source, 340mA Sink...

product image

TND512MD Picture
See larger image
SeekIC No. : 004525445 Detail

TND512MD: Features: • 3-phase high side driver.• Monolithic structure.• Allows simplified configuration of driver circuit.• Withstand voltage of 600V is assured.• Fully compatibl...

TND512MD Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
TND512MD
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/12

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• 3-phase high side driver.
• Monolithic structure.
• Allows simplified configuration of driver circuit.
• Withstand voltage of 600V is assured.
• Fully compatible input to LSTTL/CMOS.
• High-speed switching.
• Output current : 170mA Source, 340mA Sink.




Pinout






Specifications

Absolute maximum ratings
VS [V] 600
Electrical characteristics
IO Source [mA] 200
IO Sink [mA] 400


Parameter Symbol Conditions Ratings Unit
High Side Floating Supply Voltage VH -0.3 to 625 V
High Side Floating Supply Offset Voltage VFG VH-25 to VH+0.3 V
High Side Output Voltage VOUT VFG-0.3 to VH+0.3 V
Logic Supply Voltage VDD -0.3 to 25 V
Logic Input Voltage(UIN, VIN, WIN) VIN -0.3 to VDD+0.3 V
Allowable Power Dissipation PD When mounted on ceramic substrate (250mm2✕0.8mm) 1unit 0.9 W
Junction Temperature Tj -55 to +150
Storage Temperature Tstg -55 to +150
