U2407B

· Multiple gradient monitoring
· Temperature window (T_min/T_max)
· Exact currentless measurement
· Four LED status outputs
· Linear power control
· Preferred for externally regulated current sources
· Preformation algorithm for drained batteries
· Programmable top-off charge function

· Primary switch mode
· AC/ DC wall plug adapter
· Ultra fast charger (10 minutes)

The bipolar IC U2407B is a fast charge battery controller for drained NiCd/ NiMH batteries. Apart from phase control, it is identical with U2405B, but has four LED outputs. The IC enables the designer to create an efficient and economic charge system. The U2407B incorporates an intelligent multiple-gradient battery-voltage monitoring combined with temperature and failure mode detection. With automatic top-off charging, the integrated circuit ensures that the charge device stops regular charging before the critical stage of overcharging is achieved. It incorporates an additional algorithm for reactivating fully drained batteries especially after long time storage. It has four LED driver outputs for different indications of the charge status.
