U6803B

 ` Three input comparators with Schmitt-trigger characteristic
 ` Input clamping current capability to±10 mA
 ` Integrated protection cells (EMC, ESD, RF) dedicated to all input stages
 ` Common shutdown by junction temperature monitor
 ` Low voltage reset with hysteresis
 ` ESD protection to human body model:±2000 V (C = 100 pF, R = 1.5 k)
 ` Output stages:
      Short circuit protected with diode
      Load-dump protected @ 1 k
     No crosstalk on adjacent channels
     Clamping current @ 2 mA
     Jump start possible

The triple-driver IC U6803B includes three non inverted and current limited output stages with an open collector.Common thermal shutdown protects outputs against critical junction temperature. Each output can sink 20 mA, parallel output operation is possible. The digital inputs of U6803B have Schmitt-trigger function with pull-up current sources to 5 V.
