MFG:Texas Instruments Category:Integrated Circuits (ICs)
Category: Integrated Circuits (ICs)
MFG: Texas Instruments
Descriptions: IC CUR-MODE PWM CONT 16-SOIC
240
1.52600
366.24
| Technical/Catalog Information | UC2842ADW |
| Vendor | Texas Instruments |
| Category | Integrated Circuits (ICs) |
| PWM Type | Current Mode |
| Number of Outputs | 1 |
| Package / Case | 16-SOIC (7.5mm Width) |
| Packaging | Tube |
| Duty Cycle | 100% |
| Voltage - Supply | 16 V ~ 30 V |
| Frequency-Max | 450kHz |
| Buck | No |
| Boost | Yes |
| Flyback | Yes |
| Inverting | No |
| Doubler | No |
| Divider | No |
| Cuk | No |
| Isolated | No |
| Drawing Number | 296; 4040000-2; DW; 16 |
| Operating Temperature | -40°C ~ 85°C |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | UC2842ADW UC2842ADW |
UC2842ADW
PDF/DataSheet Download
IC CTRLR PWM CURRENT MODE 8SOIC
IC CUR MODE PWM CONT 8-SOIC
The UC2842AD is designed as one kind of current mode PWM controller that belongs to the UC2842 family. This device has the UVLO threshold of 16V (on) and 10V (off), this UVLO threshold can be used in off-line applications, and could operates to duty cycles a...
The UC2842A/3A/4A/5A has the following features including Optimized for Off-line and DC to DC Converters;Low Start Up Current (<0.5mA);Trimmed Oscillator Discharge Current;Automatic Feed Forward Compensation;Pulse-by-Pulse Current Limiting;Enhanced Load ...
The UC384xA family of controlICs provides the nec- essary features to implement off-line or DC to DC fixed frequency current mode control schemes with a minimal external parts count. Internally imple-mented circuits include a trimmed oscillator for pre-cise ...
The UC1842/3/4/5 family of control ICs provides the necessary features to implement off-line or DC to DC fixed frequency current mode control schemes with a minimal external parts count. Internally implemented circuits include under-voltage lockout featuring...
