Part Number: UPC2799
Description: The UHF Band frequency converter is manufactured using the (FT 20 GHz) NESAT III process . This 5V IC consists of a RF ...
- Table of contents:
UPC2799
-
Suppliers
DataSheet
General Description
UPC2799 General Description
The UHF Band frequency converter is manufactured using the (FT 20 GHz) NESAT III process . This 5V IC consists of a RF Gain control amplifier, linear, Gilbert cell mixer, two stages of LO buffering, local oscillator, external filter port, and a temperature compensation circuit. This device was specifically designed for CATV, Modems, HFC Telephony and other Multimedia applications.
NEC's stringent quality assurance and test procedures assure the highest reliability and performance.
UPC2799 Features
• 50-860 MHz RF FREQUENCY RANGE
• 50-1800 MHz LO RANGE
• 15 dB VARIABLE GAIN RF AMP
• +5 dB dBm IIP3 MIXER
• 8 dB RF CONVERSION GAIN
• BUFFERED LO OUTPUT
• 50-1800 MHz LO RANGE
• 15 dB VARIABLE GAIN RF AMP
• +5 dB dBm IIP3 MIXER
• 8 dB RF CONVERSION GAIN
• BUFFERED LO OUTPUT
UPC2799 Connection Diagram
UPC1028H
