VC0702

VC0702 is a high performance video camera device designed for applications that requiring small package, low voltage, low power consumption. It supports various video outputs, such as interlaced/progressive PAL/NTSC composite video output, RGB/YCbCr component video output, and S-Video output. The devices use VC0702 can directly link with a VCR, TV monitor or other A/V device.

VC0702 can be designed in applications, such as security, surveillance, video conference, video phone, vision-enabled toys, digital camcorder, and medical equipment. It works in a low voltage and low power consumption environment and requires only a single 3.3 V DC power supply. VC0702 has motion detection and trigger function which targets to automatic surveillance applications.

VC0702 has two different variations as listed in the below table. They have the same functionalities, but the packages are different.
