W981616BH

W981616BH is a high-speed synchronous dynamic random access memory (SDRAM), organized as 512K words *2 banks * 16 bits. Using pipelined architecture and 0.175 mm process technology, it delivers a data bandwidth of up to 332M bytes per second (-5). For different applications the W981616BH is sorted into the following speed grades: -5, -6, and 7(L).

Accesses to the SDRAM W91640 are burst oriented. Consecutive memory location in one page can be accessed at a burst length of 1, 2, 4, 8 or full page when a bank and row is selected by an ACTIVE command. Column addresses are automatically generated by the SDRAM internal counter in burst operation. Random column read W91640 is also possible by providing its address at each clock cycle. The multiple bank nature enables interleaving among internal banks to hide the precharging time.

By having a programmable Mode Register, the system can change burst length, latency cycle, interleave or sequential burst to maximize its performance. W981616BH is ideal for main memory in high performance applications.
