Product Details

Description



Features:

The Word-Wide FlashFile memory family maintains basic compatibility with Intel's 28F016SA and 28F016SV. Key enhancements include:

• Common Flash Interface (CFI) Support
•  Scaleable Command Set (SCS) Support
•  Low Voltage Technology
• Enhanced Suspend Capabilities

They share a compatible Status Register, basic software commands, and pinout. These similarities enable a clean migration from the 28F016SA or 28F016SV. When upgrading, it is important to note  the following differences:

• Because of new feature and density options,the devices have different manufacturer and device identifier codes. This allows for software optimization.
• New software commands.
• To take advantage of low voltage on the 28F160S3 and 28F320S3, allow VPP connection to VCC. The 28F160S3 and 28F320S3 do not support a 12V VPP option.




Pinout

Connection Diagram


Specifications

Temperature under Bias ................ 40°C to +85°C
Storage Temperature................... 65°C to +125°C
Voltage On Any Pin
(except VCC and VPP )
         .................................... 0.5V to + VCC +0.5V(1)
VCC Supply Voltage ............    0.2V to + VCC+0.5V(1)
VPP Update Voltage during
Block Erase, Flash Write, and
Lock-Bit Configuration ...........           0.2V to +7.0V(2)
Output Short Circuit Current.....................     100 mA(3)


Description

This datasheet contains 16- and 32-Mbit Word-Wide FlashFileTM memory (28F160S3 and 28F320S3) specifications. Section 1 provides a flash memory overview. Sections 2, 3, 4, and 5 describe the memory organization and functionality.Section 6 covers electrical specifications for extended temperature product offerings.
