LNA2402L

IR LED 950NM 8 DEG TO-18

product image

LNA2402L Picture
See larger image
SeekIC No. : 003612114 Detail

LNA2402L: IR LED 950NM 8 DEG TO-18

LNA2402L Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
LNA2402L
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: - Manufacturer: Panasonic Electronic Components - Semiconductor Products
Current - DC Forward (If): 100mA Radiant Intensity (Ie) Min @ If: -
Wavelength: 950nm Voltage - Forward (Vf) Typ: 1.3V
Viewing Angle: 16° Orientation: Top View
Maximum Power Dissipation : 568 mW Mounting Type: Through Hole
Package / Case: TO-18-2 Metal Can

Description

Series: -
Current - DC Forward (If): 100mA
Wavelength: 950nm
Voltage - Forward (Vf) Typ: 1.3V
Orientation: Top View
Radiant Intensity (Ie) Min @ If: -
Packaging: -
Mounting Type: Through Hole
Manufacturer: Panasonic Electronic Components - Semiconductor Products
Viewing Angle: 16°
Package / Case: TO-18-2 Metal Can


Features:

`High-power output, high-efficiency : PO = 7.5 mW (typ.)
`Fast response and high-speed modulation capability : tr, tf = 1 s (typ.)
`Infrared light emission close to monochromatic light : P = 950 nm (typ.)
`Narrow directivity, suitable for effective use of radiant power (LNA2402L (LN151L))
`Wide directivity, matched for external optical systems (LNA2403F (LN151F))
`TO-18 standard type package


Specifications

Parameter Symbol Ratings Unit
Power dissipation PD 160 mW
Forward current (DC) IF 100 mA
Pulse forward current IFP* 2 A
Reverse voltage (DC) VR 3 V
Operating ambient temperature Topr 25 to +100 ˚C
Storage temperature Tstg 30 to+100 ˚C

* f = 100 Hz, Duty cycle = 0.1 %




Parameters:

Technical/Catalog InformationLNA2402L
VendorPanasonic - SSG
CategoryOptoelectronics
Voltage - Forward (Vf) Typ1.3V
Current - DC Forward (If)100mA
Wavelength950nm
Viewing Angle16°
Radiant Intensity (Ie) Min @ If-
Mounting TypeThrough Hole
Package / CaseTO-18
OrientationTop View
Packaging-
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names LNA2402L
LNA2402L
