The AS211-334 is an IC FET SPDT switch in a low cost miniature LGA package. The AS211-334 features lowinsertion loss and positive voltage operation with very low DC power consumption.
AS211-334 Maximum Ratings
Characteristic
Value
RF Input Power
6 W > 500 MHz 0/+7 V Control
Control Voltage
-0.2 V, +8 V
Operating Temperature
-40°C to +85°C
Storage Temperature
-65°C to +150°C
JC
25°C/W
AS211-334 Features
P1dB +30 dBm Typical @ +3 V IP3 43 dBm Typical @ +3 V Low Insertion Loss (0.3 dB @ 0.9 GHz) Low DC Power Consumption 1.5 x 1.2 x 0.8 mm Land Grid Array (LGA) Package PHEMT Process
AS211-334 Typical Application
General Purpose Switch for Telecommunication Applications
