LM201A General Description

The LM101A series are general purpose operational amplifiers which feature improved performance over industry standards like the LM709. Advanced processing techniques make possible an order of magnitude reduction in input currents, and a redesign of the biasing circuitry reduces the temperature drift of input current. Improved specifications include:
• Offset voltage 3 mV maximum over temperature (LM101A/LM201A)
• Input current 100 nA maximum over temperature (LM101A/LM201A)
• Offset current 20 nA maximum over temperature (LM101A/LM201A)
• Guaranteed drift characteristics
• Offsets guaranteed over entire common mode and supply voltage ranges
• Slew rate of 10V/µs as a summing amplifier

This amplifier offers many features which make its application nearly foolproof: overload protection on the inputand output, no latch-up when the common mode range is exceeded, and freedom from oscillations and compensation with a single 30 pF capacitor. It has advantages over internally compensated amplifiers in that the frequency compensation can be tailored to the particular application. For example, in low frequency circuits it can be overcompensated for increased stability margin. Or the compensation can be optimized to give more than a factor of ten improvement in high frequency performance for most applications. In addition, the device provides better accuracy and lower noise in high impedance circuitry. The low input currents
also make it particularly well suited for long interval integrators or timers, sample and hold circuits and low frequency waveform generators. Further, replacing circuits where matched transistor pairs buffer the inputs of conventional IC op amps, it can give lower offset voltage and a drift at a lower cost.

The LM101A is guaranteed over a temperature range of −55 to +125, the LM201A from −25 to +85, and the LM301A from 0 to +70.

LM201A Maximum Ratings

                                                                               LM101A/LM201A                              LM301A
Supply Voltage .......................................................................±22V .................................±18V
Differential Input Voltage .......................................................±30V .................................±30V
Input Voltage (Note 3) ...........................................................±15V .................................±15V
Output Short Circuit Duration (Note 4) ..........................Continuous ........................Continuous
Operating Ambient Temp. Range .......−55°C to +125°C (LM101A) ..................0°C to +70°C
.............................................................−25°C to +85°C (LM201A)
TJ Max
H-Package ................................................................150°C 100°C
N-Package ................................................................150°C 100°C
J-Package .................................................................150°C 100°C
Power Dissipation at TA = 25°C
H-Package (Still Air) .............................................................500 mW ...............................300 mW
(400 LF/Min Air Flow) .........................................................1200 mW ...............................700 mW
N-Package ...........................................................................900 mW ...............................500 mW
J-Package ..........................................................................1000 mW ...............................650 mW
Thermal Resistance (Typical) θjA
H-Package (Still Air) ..........................................................165°C/W .............................165°C/W
(400 LF/Min Air Flow) ..........................................................67°C/W ...............................67°C/W
N Package ........................................................................135°C/W ..............................135°C/W
J-Package .........................................................................110°C/W ............................110°CmW
Typical) θjC
H-Package ..........................................................................25°C/W ................................25°C/W
Storage Temperature Range ..............................−65°C to +150°C ...............−65°C to +150°C
Lead Temperature (Soldering, 10 sec.)
Metal Can or Ceramic ............................................................300°C ..................................300°C
Plastic ....................................................................................260°C ..................................260°C
ESD Tolerance (Note 7) ...........................................................2000V ...................................2000V

LM201A Connection Diagram
