Product :
Fuse Size / Group :
Current Rating :
Voltage Rating :
Mounting Style :
Body Material :
Number of Poles :
Termination Style :
Operating Temperature Range :


Features:

Broadband Frequency Ranges
 Environmentally Sealed
Feedback Leveling
Small Size
Reduced VSWR


Specifications



Parameter	Absolute Maximum
Operating Temperature	-55°C to +85°C
Storage Temperature	-65°C to +125°C

Description

M/A-COM's standard limiter series 2690 is a line of completely passive solid state receiver protectors. They exhibit octave and multi-octave performance using a unique construction technique involving PIN diodes in broadband microstrip circuits. Careful diode selection allows a variety of device performance, trading off peak and average power handling, spike leakage and recovery time. Typical 2690 insertion loss and VSWR curves are shown below.
