Features:

• 2718AF2 and 2718AH2 operate over the frequency range from 1kHz to 1.1MHz
• 2718BK2 operates over the frequency range from 500Hz to 1.1MHz
• Designed for broadband applications
• Minimum interwinding breakdown voltage of 1500 Vrms
• Qualified per Bellcore TR-TSY-000357-1


Pinout

Connection Diagram


Specifications

Part Number
Turns Ratio
± 3%
Primary
Inductance
mH min
DCR

max
Insertion Loss
dB typ
Frequency
Response
dB
Interwinding
Capacitance
pF max
Pri : Sec
Pri
Sec
1kHz
1MHz
2718AF2
1.0 : 1.0
25.5
2.80
2.30
0.20
0.50
0.50
7.0*
2718AH2
1.0 : 1.0
25.5
2.80
2.30
0.20
0.50
0.50
10.0
2718AK2
1.0 : 1.0
11.0
1.50
1.50
N/A
N/A
N/A
30
