2SA2186

Features: ·Adoption of MBIT processes.·High current capacity.·Low collector-to-emitter saturation voltage.·High-speed switching.Application·Voltage regulators, relay drivers, lamp drivers, electrical equipment.PinoutSpecifications Absolute maximum ratings VCEO [V] 50 IC [A] 2 ...

product image

2SA2186 Picture
See larger image
SeekIC No. : 004220473 Detail

2SA2186: Features: ·Adoption of MBIT processes.·High current capacity.·Low collector-to-emitter saturation voltage.·High-speed switching.Application·Voltage regulators, relay drivers, lamp drivers, electrica...

2SA2186 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
2SA2186
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/4

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Adoption of MBIT processes.
·High current capacity.
·Low collector-to-emitter saturation voltage.
·High-speed switching.




Application

·Voltage regulators, relay drivers, lamp drivers, electrical equipment.




Pinout






Specifications

Absolute maximum ratings
VCEO [V] 50
IC [A] 2
PC [W] 0.9
Electrical characteristics
hFE min 200
hFE max 560
VCE [V] 2
IC [A] 0.1
VCE (sat) typ [V] 0.22
VCE (sat) max [V] 0.43
IC [A] 1
IB [mA] 50


Parameter
Symbol
 Conditions
Ratings
Unit
Collector-to-Base Voltage
VCBO
-50
V
Collector-to-Emitter Voltage
VCEO
-50
V
Emitter-to-Base Voltage
VEBO
-6
V
Collector Current
IC
-2
A
Collector Current (Pulse)
ICP
-4
A
Base Current
IB
-400
mA
Collector Dissipation
PC
0.9
W
Junction Temperature
Tj
150
Storage Temperature
Tstg
-55 to +150
