Features:

· High DC current gain.
· Large current capacity and large ASO.
· Low saturation volatage.
· Micaless package facilitating mounting.




Pinout






Specifications

Parameter Symbol Conditions Ratings Unit
Collector-to-Base Voltage VCBO ()110 V
Collector-to-Emitter Voltage VCEO ()100 V
Emitter-to-Base Voltage VEBO ()6 V
Collector Current IC ()10 A
Collector Current (Pulse) ICP ()15 A
Collector Dissipation PC 3.0 W
Tc=25°C 45 W
Junction Temperature Tj 150 °C
Storage Temperature Tstg 55 to +150 °C


Absolute maximum ratings
VCEO [V] 100
IC [A] 10
PC Tc=25°C [W] 45
Electrical characteristics
hFE min 1500
VCE [V] 3
IC [A] 5
VCE (sat) max [V] 1.5
IC [A] 5
IB [mA] 10
fT typ [MHz] 20
Resistance R1/R2 [] 6000/200





Description

The 2SB1388 feature:

· Motor drivers, printer hammer drivers, relay drivers, voltage regulator control.
