2SC2412K

The 2SC2412K is one member of the 2SC2412 family which is designed as the NPN silicon general purpose transistor device that has four points of features:(1)low Cob; (2)Cob=2.0 pF; (3)compements the 2SA1037K; (4)RoHS compliant product. And this device has the structure of NPN silicon teansistor and expitaxial planar type.

The absolute maximum ratings of the 2SC2412K can be summarized as:(1)Collector-base voltage: 60 V;(2)Collector-emitter voltage: 50 V;(3)Emitter-base voltage: 7 V;(4)Collector current: 0.15 A;(5)Collector power dissipation: 0.2 W;(6)Junction temperature: 150 ;(7)Storage temperature: -55 to +150 .

The electrical characteristics of this device can be summarized as:(1)Collector-base breakdown voltage: 60 V;(2)Collector-emitter breakdown voltage: 50 V;(3)Emitter-base breakdown voltage: 7 V;(4)Collector cutoff current: 0.1 uA;(5)Emitter cutoff current: 0.1 uA;(6)DC current transfer ratio: 120 to 560;(7)Collector-emitter saturation voltage: 0.4 V;(8)Transition frequency: 180 MHz;(9)Output capacitance: 2 to 3.5 pF. If you want to know more information such as the electrical characteristics about the 2SC2412K, please download the datasheet in www.seekic.com or www.chinaicmart.com.
