Part Number: 421501









Description: The Extech 421501 Type K Digital Thermometer ,which is wate resistace ,...


Urgent Purchase

421501 General Description


      The Extech 421501 Type K Digital Thermometer ,which is wate resistace ,measures temperature with a Type K thermocouple. The thermocouple attaches to the meter with a sub-miniature plug. The meter's display is backlit and includes a Data Hold feature. Other features include Max Temperature and selectable units/resolution. This meter is shipped fully tested and calibrated and, with proper use, will provide years of reliable service.
     There are nine parts of the whole product, which is thermocouple plug , LCD display, power on/off button , resolution select button , maximum reading mode button, rubber protective jacket,  unit of measure o C/ o F select key, backlight activation key , data hold key  while battery compartment and tilt santd on rear of meter.
     Then, there are some specifications about it. Display is 3-1/2 digit LCD (2000 counts). Battery Power Supply is 9V DC battery. Battery life is 200 hours typical. Dimensions is 7.5 x 3.6 x 2.1" (192 x 91 x 52.5mm). Weight is 11.7oz. (365g). Temperature units is selectable oC or oF temperature units. Accuracy of meter is ±(0.3% of reading + 1oC) from -50oC to 1000oC,±(0.5% of reading + 1oC) from 1000oC to 1300oC and ±(0.3% of reading + 2oF) from -58oF to 2000oF. Temperature Coefficient is 0.1 times the applicable accuracy specifications per oC from 0oC to 18oC and 28oC to 50oC (32oF to 64oF and 82oF to 122oF). Water resistant housing is gasket protected front panel. Input Protection is 24VAC/DC max. input on any combination of inputs. Reading rate is 2.5 times per second. Thermocouple connection is that meter accepts standard subminiature connector.Operating conditions is from 32oF to 122oF (0oC to 50oC)(less than 80%RH). Storage conditions is from -4oF to 140oF (-20oC to 60oC)(less than 70% RH).
     Above information is just a simple introduction about it and if you want to get more detailed information about it , please be hurry to go to our web where you will find more excellent products! Thanks for your concern!
