Description



Features:






Specifications






Description

5STP28L4200 is a type of phase control thyristor which has five unique features: The first one is low on-state and switching losses. The second one is patented free-floating silicon technology. The third one is it is designed for traction, energy and industrial applications.The forth one is optimum power handling capability. The last one is interdigitated amplifying gate.

There are some specifications about 5STP28L4200.VSM is 4200 V.ITAVM is 3170 A.ITRMS is 4980 A.ITSM is 52000 A.VT0 is 0.97V.rT is 0.158 m.Mounting force (FM) is 63 kN min, 70 kNtyp and 84 kN max.Acceleration (a) is (Device unclamped) 50 m/s2.Acceleration (a) is( Device clamped) 100 m/s2.Weight(m) is 1.45 kg typ.Surface creepage distance(DS) is 36 mm min.Air strike distance (Da) is 15 mm min.On-state:Max. average on-state current(ITAVM)( Half sine wave, Tc = 70°C) is 3170 A max.Max.RMS on-state current (ITRMS)( Half sine wave, Tc = 70°C) is 4980 A max.Max. peak non-repetitive surge current(ITSM)(tp = 10 ms, Tj = 125°C, VD=VR = 0 V) is 52000 A max.Limiting load integral(I2t)(tp = 10 ms, Tj = 125°C, VD=VR = 0 V) is 13520 kA2s max.Limiting load integral(I2t)(tp = 8.3 ms, Tj = 125°C,VD=VR=0 V) is 13014 kA2s max.

Well, this is a simple introduction to this type of product, if you want to know more about 5STP28L4200, please pay more attention to our web. Thanks for your attention!
