7011X1/7: Standard LED - SMD BI-COLOR SMT LED

7011X1/7 Data Sheet

US $ .23~.26 / Piece | Get Latest Price

Part Number:: 7011X1/7
Mfg:: Chicago Miniature
Supply Ability:: 5000

Price Break

Qty
0~1450
1450~2000
2000~2500
2500~5000

Unit Price
$.26
$.25
$.25
$.23

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

7011 evaluate
RF Inductors 12.5uH 15%
70110 evaluate
US $3.68 - 3.68 / Piece

SOCKET TORX 3/8" SQ DRIVE TR10
701110 evaluate
Development Software FUZZY LOGIC CD FOR C2xxx

Product Details

Quick Details

Packaging :

Reel

Description

LED Size :
Illumination Color :
Wavelength/Color Temperature :
Lens Color/Style :
Forward Current :
Forward Voltage :
Luminous Intensity :
Viewing Angle :
Packaging : Reel

Pinout

Specifications

Part Number: 7011X1/7
Serial Number: 7011X
LED Type: SMT
Industry Size: 1210
Metric Size: 3.0 x 2.5 x 1.1 mm
Output Color: RED/YELLOW
Epoxy: CLEAR NON-DIFFUSED
Peak Wave length (mA): 660/570
Minimum MCD: 6.0/6.0
Typical MCD: 17.0/12.0
Forward Volt (Typical): 1.7/2.1
Forward Volt (Max): 2.0/2.5
Rate Current (mA): 20
Viewing Angle (°): 100
Operating Temperature: -0.352941176
Storage Temperature: -0.333333333
Power Dissipation: 60/75
Cont Forward Current Max: 30
RoHS Status: Yes

Parameters:

Technical/Catalog Information	7011X1/7
Vendor	CML Innovative Technologies Inc
Category	Optoelectronics
Color	Red, Yellow
Lens Style/Size	Rectangle, 2.5mm x 2mm
Millicandela Rating	6mcd Red, 3mcd Yellow
Voltage - Forward (Vf) Typ	1.7V Red, 2.1V Yellow
Wavelength - Dominant	660nm, 570nm
Wavelength - Peak	660nm, 570nm
Current - Test	20mA
Viewing Angle	100°
Lens Type	Clear
Luminous Flux	13 mlm Red, 7 mlm Yellow
Package / Case	1210 (3225 metric)
Mounting Type	Surface Mount
Packaging	Tape & Reel (TR)
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	7011X1 7 7011X17 L61017TR ND L61017TRND L61017TR
