7469

Features: •Dual output5 V (±2%), 320mA and 2.6 V1) (±4%), 300mA or5 V (±2%), 320mA and 3.3 V (±3%), 300mA•Ultra low quiescent current consumption < 55 A•Inhibit function•Very low dropout voltage•Reset with power-on delay•Early Warning comparator•Window ...

product image

7469 Picture
See larger image
SeekIC No. : 004248525 Detail

7469: Features: •Dual output5 V (±2%), 320mA and 2.6 V1) (±4%), 300mA or5 V (±2%), 320mA and 3.3 V (±3%), 300mA•Ultra low quiescent current consumption < 55 A•Inhibit function•V...

7469 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
7469
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

•Dual output
5 V (±2%), 320mA and 2.6 V1) (±4%), 300mA or
5 V (±2%), 320mA and 3.3 V (±3%), 300mA
•Ultra low quiescent current consumption < 55 A
•Inhibit function
•Very low dropout voltage
•Reset with power-on delay
•Early Warning comparator
•Window watchdog
•Power sequencing for dual voltage C
•Output protected against short circuit
•Wide operation range: up to 45 V
•Wide temperature range: -40 °C to 150 °C
•Overtemperature protection
•Overload protection


Specifications

Parameter Symbol Limit Values Unit Remarks
Min. Max.
Input I1
Voltage VI1 -0.3 45 V
Current VI1 mA Internally limited
Input I2
Voltage VI2 -0.3 45 V
Current VI2 mA Internally limited
Output Q1
Voltage VQ1 -0.3 5.5 V Permanent
Voltage VQ1 -0.3 6.2 V t < 10 s1)
Current IQ1 mA Internally limited
Output Q2
Voltage VQ2 -0.3 5.5 V Permanent
Voltage VQ2 -0.3 6.2 V t < 10 s1)
Current IQ2 mA Internally limited
Inhibit InputINH
Voltage VINH -0.3 45 V Observe current limit IINHmax2)
Current IINH -1 -1 mA
Reset Output RO
Voltage VRO -0.3 5.5 V Permanent
Voltage VRO -0.3 6.2 V t < 10 s1)
Current IRO mA internally limited
Delay Timing DT
Voltage VDT -0.3 5.5 V Permanent
Voltage VDT -0.3 6.2 V t < 10 s1)
Current IDT -5 -5 mA



Description

The TLE 7469 is a monolithic integrated voltage regulator with two voltage outputs specially designed to supply  icrocontrollers with dual supply voltage: 2.6 V1) or 3.3 V core and 5 V I/O voltage like the Infineon XC164 and XC161.
