74AC374

Features:

*I_CC and I_OZ reduced by 50%
*Buffered positive edge-triggered clock
*3-STATE outputs for bus-oriented applications
*Outputs source/sink 24 mA
*See 273 for reset version
*See 377 for clock enable version
*See 373 for transparent latch version
*See 574 for broadside pinout version
*See 564 for broadside pinout version with inverted outputs
*ACT374 has TTL-compatible inputs

Pinout




Specifications

Supply Voltage (V_CC)                                           0.5V to+7.0V
DC Input Diode Current (I_IK )
V_I =-0.5V                                                                       -20 mA
V_I=V_CC+0.5V                                                                +20 mA

DC Input Voltage (V_I)                                    -0.5V to V_CC+0.5V
DC Output Diode Current (I_OK)
V_O =-0.5V                                                                      -20 mA
V_O  V_CC+ 0.5V                                                              +20 mA
 DC Output Voltage (V_O )                              -0.5V to V_CC+0.5V

DC Output Source
or Sink Current (I_O)                                                       ±50 mA
DC V_CC or Ground Current
per Output Pin (I_CC or I_GND )                                         ±50 mA
Storage Temperature (T_STG)                               -65 to+150
Junction Temperature (T_J )
(PDIP)                                                                                140


Description

  The 74AC374 is a high-speed, low-power octal D-type flip-flop featuring separate D-type inputs for each flip-flop and 3-STATE outputs for bus-oriented applications. A buff-ered Clock (CP) and Output Enable (OE) are common to all flip-flops.
