Purchase 74HC02N,652, In-stock 74HC02N,652 From SeekIC.

MFG:NXP Semiconductors  Category:Integrated Circuits (ICs)

74HC02N,652

74H Series Datasheet download

Five Points

Part Number: 74HC02N,652

Category: Integrated Circuits (ICs)

MFG: NXP Semiconductors





Descriptions: IC GATE NOR QUAD 2INPUT 14DIP

Price Break

1
25
100
250
500
1000
5000

Unit Price

.45000
.36400
.24950
.18712
.14554
.12474
.11088

Extended Price

0.45
9.10
24.95
46.78
72.77
124.74
554.40

(All prices are in USD) Prices for reference only
Urgent Purchase

74HC02N,652 General Description

IC GATE NOR QUAD 2INPUT 14DIP

74HC02N,652 Parameters

Technical/Catalog Information74HC02N,652
VendorNXP Semiconductors
CategoryIntegrated Circuits (ICs)
Number of Circuits4 - Quad
Package / Case14-DIP (300 mil)
Logic TypeNOR Gate
PackagingTube
Mounting TypeThrough Hole
Number of Inputs2
Current - Output High, Low5.2mA, 5.2mA
Supply Voltage2 V ~ 6 V
Operating Temperature-40°C ~ 125°C
Voltage - Supply2 V ~ 6 V
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names 74HC02N,652
74HC02N,652
568 1382 5 ND
56813825ND
568-1382-5
