MFG:ST Package Cooled:SOT23-8L D/C:06+
MFG: ST
Package Cooled: SOT23-8L
D/C: 06+
Description: The 74V2G00 is an advanced high-speed CMOS DUAL 2-INPUT NAND GATE fabricated with sub-micron silicon g...
The 74V2G00 is an advanced high-speed CMOS DUAL 2-INPUT NAND GATE fabricated with sub-micron silicon gate and double-layer metal wiring C2MOS technology.
The internal circuit is composed of 3 stages including buffer output, which provide high noise immunity and stable output.
Power down protection is provided on all inputs and outputs and 0 to 7V can be accepted on inputs with no regard to the supply voltage. This device can be used to interface 5V to 3V.
|
Symbol |
Parameter |
Value |
Units |
|
VCC |
Supply Voltage |
-0.5 to +7.0 |
V |
|
VI |
DC Input Voltage |
-0.5 to +7.0 |
V |
|
VIC |
DC Output Voltage (see note 1) |
-0.5 to +7.0 |
V |
|
VO |
DC Output Voltage (see note 2) |
-0.5 to VCC + 0.5 |
V |
|
IIK |
DC Input Diode Current |
- 20 |
mA |
|
IOK |
DC Output Diode Current |
- 20 |
mA |
|
IO |
DC Output Current |
± 25 |
mA |
|
ICC or IGND |
DC VCC or Ground Current |
± 50 |
mA |
|
Tstg |
Storage Temperature |
-65 to +150 |
°C |
|
TL |
Lead Temperature (10 sec) |
260 |
°C |
74V2G00
PDF/DataSheet Download
IC GATE EXCLU OR SGL SOT23-5
IC GATE XOR SINGLE SOT323-5
