7610D2

Color :
Material :
Product : Rigid Light Pipe
Body Shape : Rectangular
LED Size : 0805
Body Length : 20.32 mm


Features:

• Precision engineered with ray tracing for bright, optically precise even indication and attractive appearance.
• ESD protection from circuitry for exceptional reliability.
• Optimized for use with Bright Chips™ SMT LEDs.
• High contrast and wide viewing angle for greater visibility.
• Available in a variety of colors for added contrast and aesthetics.
• Parts inserted after reflow to permit LED pad inspection before assembly.
• Low profile for height constrained applications.
• Large 2.5 x 7.5 mm surface provides high visibility.
• Ideal for bar graph displays.
• 7610D2 is designed for use with 7012X Series Bright Chip LEDs.




Pinout






Specifications

Part Number: 7610D2
Serial Number: 7610
LED type: SMD LED
Type: Right Angle, Single Position
Mounting: PCB Press-In Pin
Works with: 7012X Series
Housing ul rating: UL 94-V0
RoHS Status: Yes




Description

7610D2. Bright•Pipes™ Optical Lightpipes produce bright, even indication based on optical ray tracing. They conveniently and economically conduct light from SMT LEDs through angles and distances to a viewable front lense surface in order to provide an attractive, bright and even indication of equipment of function status with a minimal attenuation of light output through the optical fibers that join the base, at the LED light source, to the lens front.




Parameters:

Technical/Catalog Information	7610D2
Vendor	CML Innovative Technologies Inc
Category	Optoelectronics
Color	Clear
Mounting Type	PCB, Right Angle
Lens Style/Size	Round, 8mm
Configuration	Single
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	7610D2 7610D2 L71300 ND L71300ND L71300
