Purchase 78ST300, In-stock 78ST300 From SeekIC.
Part Number: 78ST300
Description: The 78ST300 is a series of wide input voltage, 3 terminal Integrated Switching Regulators (ISRs). Empl...
- Table of contents:
78ST300
-
Suppliers
DataSheet
General Description
78ST300 General Description
The 78ST300 is a series of wide input voltage, 3 terminal Integrated Switching Regulators (ISRs). Employing a ceramic substrate, these ISRs have a maximum output current of 3A.
The output voltage is laser trimmed for high accuracy.
The 78ST300 series regulators have internal short-circuit and overtemperature protection and may be used in a wide variety of applications.
78ST300 Features
• High Efficiency > 80%
• Wide Input Range
• Self-Contained Inductor
• Short-Circuit Protection
• Over-Temperature Protection
• Fast Transient Response
• Wide Input Range
• Self-Contained Inductor
• Short-Circuit Protection
• Over-Temperature Protection
• Fast Transient Response
78ST300
PDF/DataSheet Download
- Datasheet: 78ST300
- File Size: 194626 KB
- Manufacturer: TI [Texas Instruments]
- Click here to Download
