Purchase 80C31BH, In-stock 80C31BH From SeekIC.
MFG:INTEL Package Cooled:DIP D/C:07+
- Table of contents:
80C31BH
-
Suppliers
DataSheet
General Description
80C31BH Maximum Ratings
Ambient TemperatureUnderBias .............-40to 85
Storage Temperature ...........................-65to 150
Voltage onEAVPP Pinto VSS...................... 0V to 130V
Voltage on Any Other Pinto VSS ..............-0.5V to 65V
Maximum IOL perIOPin .......................................15mA
Power Dissipation.................................................15W
(Based on package heat transfer limitations not de-vice power consumption)
NOTICE This data sheet contains preliminary infor-mation on new products in production It is valid for the devices indicated in the revision history The specifications are subject to change without notice
WARNING Stressing the device beyond the ''Absolute Maximum Ratings'' may cause permanent damage These are stress ratings only Operation beyond the''Operating Conditions'' is not recommended and ex-tended exposure beyond the ''Operating Conditions''may affect device reliability
80C31BH Features
High Performance CHMOS EPROM
24 MHz Operation
Improved Quick-Pulse Programming Algorithm
3-Level Program Memory Lock
Boolean Processor
128-Byte Data RAM
32 Programmable IO Lines
Two 16-Bit TimerCounters
Extended Temperature Range( 40to 85)
5 Interrupt Sources
Programmable Serial Port
TTL- and CMOS-Compatible Logic Levels
64K External Program Memory Space
64K External Data Memory Space
ONCE Mode Facilitates System Testing
Power Control Modes
-Idle
-Power Down
24 MHz Operation
Improved Quick-Pulse Programming Algorithm
3-Level Program Memory Lock
Boolean Processor
128-Byte Data RAM
32 Programmable IO Lines
Two 16-Bit TimerCounters
Extended Temperature Range( 40to 85)
5 Interrupt Sources
Programmable Serial Port
TTL- and CMOS-Compatible Logic Levels
64K External Program Memory Space
64K External Data Memory Space
ONCE Mode Facilitates System Testing
Power Control Modes
-Idle
-Power Down
80C31BH Connection Diagram
80C31BH
PDF/DataSheet Download
- Datasheet: 80C31BH
- File Size: 290858 KB
- Manufacturer: INTEL [Intel Corporation]
- Click here to Download
