ACA2404

21.5 dB Gain
Characterized at +58 dBmV Output
Very Low Distortion
Excellent 75 ? Input and Output Match
Stable with High VSWR Load Conditions
Monolithic Design for Consistent Performance Part-to-Part
Surface Mount Package Compatible with Automatic Assembly
Low Cost Alternative to Hybrids
Meets Cenelec Standards

The ACA2404 is a highly linear, high output power,monolithic GaAs RF amplifier that has been developed to replace standard CATV hybrid amplifiers, in new designs. Offered in a convenient surface mount package, the MMIC consists of two pairs of parallel amplifiers that are optimized for exceptionally low distortion and noise figure. A hybrid equivalent that provides flat gain response and excellent input and output return loss over the 40 to 870 MHz CATV downstream band is formed when one ACA2404 is cascaded between two appropriate transmission line baluns.
