Series: -
Type: -
Max Output Power x Channels @ Load: -
Output Type: -
Voltage - Supply: -
Features: -
-3db Bandwidth: -
Slew Rate: 0.5 V/µs
Current - Input Bias: 30pA
Number of Circuits: 1
Voltage - Input Offset: 5000µV
Operating Temperature: -55°C ~ 125°C
Mounting Type: Through Hole
Packaging: Tube
Gain Bandwidth Product: 10kHz
Amplifier Type: Isolation
Current - Supply: 20mA
Current - Output / Channel: 4mA
Manufacturer: Analog Devices Inc
Package / Case: 38-DIP (0.500", 12.70mm), 11 Leads
Voltage - Supply, Single/Dual (±): 12 V ~ 15 V
Supplier Device Package: 11-PDIP
Features: SpecificationsDescriptionAD203SN is a kind of 10 kHz bandwidth isolation amplifier. The typical applications include engine monitoring and control, mobile multichannel data acquisition systems, instrumentation and/or control signal isolation, current shunt measurements and high voltage instrumentation amplifiers.
There are some features of AD203SN as follows. First is characterized to the full military temperature range which is from -55 to +125. The second is 10 kHz full power bandwidth. Then is wide output range which is ±10 V min (into a 2.5k load). Next is high CMV isolation which is 1500 V RMS continuous. The fifth is isolated power which is ±15 V DC @ ±5 mA. The sixth is two-port isolation through transformer coupling. The last one is low nonlinearity which is ±0.025% max.
What comes next is about the specifications of AD203SN (typical @ +25, VS=+15 V dc, unless noted otherwise). First is about the input voltage ratings. The linear differential range is ±10 V. The maximum CMV input to output AC, 60 Hz, continuous is 1500 V rms. The maximum leakage current input to output is 4.0A rms at 240 V rms, 60 Hz. Then is about the rated output. The minimum voltage (OUT HI to OUT LO) @ RL=5.0 k is ±10 V. The output resistance is 0.2. The current is ±4 mA. The maximum capacitive load is 270 pF. The output ripple is 15 mV pk-pk at 100 kHz bandwidth and 0.7 mV pk-pk at 5 kHz bandwidth.
Parameters: | Technical/Catalog Information | AD203SN |
| Vendor | Analog Devices Inc |
| Category | Integrated Circuits (ICs) |
| Packaging | Tube |
| Amplifier Type | Isolation |
| Number of Circuits | 1 - Single |
| Package / Case | 38-DIP (11 Lead) |
| Slew Rate | 0.5 V/s |
| Gain Bandwidth Product | 10kHz |
| Current - Supply | 20mA |
| Current - Output / Channel | 4mA |
| Voltage - Supply, Single/Dual (±) | 12 V ~ 15 V |
| Output Type | - |
| -3db Bandwidth | - |
| Current - Input Bias | 30pA |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Input Offset | 5000V |
| Drawing Number | * |
| RoHS Status | RoHS Non-Compliant |
| Other Names | AD203SN
AD203SN
|
AD203SN Data Sheet
