Series: -
Amplifier Type: General Purpose
Type: -
Max Output Power x Channels @ Load: -
Voltage - Supply: -
Features: -
-3db Bandwidth: -
Mounting Type: Surface Mount
Current - Output / Channel: 30mA
Operating Temperature: -40°C ~ 125°C
Gain Bandwidth Product: 1MHz
Number of Circuits: 1
Output Type: Rail-to-Rail
Package / Case: SC-74A, SOT-753
Supplier Device Package: SOT-23-5
Voltage - Input Offset: 1000µV
Current - Supply: 45µA
Packaging: Cut Tape (CT)
Current - Input Bias: 4pA
Voltage - Supply, Single/Dual (±): 2.7 V ~ 5.5 V
Manufacturer: Analog Devices Inc
Slew Rate: 0.92 V/µs
Pinout
DescriptionThe AD8541ART-REEL7 is designed as one kind of microprocessor supervisory circuit device that can be used in wide range of applications such as:(1)ASIC input or output amplifier; (2)sensor interface; (3)piezo electric transducer amplifier; (4)medical instrumentation; (5)mobile communication; (6)audio output; (7)portable systems. And this device is available in 8-lead SOIC, 5-lead SC70, and 5-lead SOT-23 packages.
Features of the AD8541ART-REEL7 are:(1)single-supply operation: 2.7 V to 5.5 V; (2)low supply current: 45 uA/amplifier; (3)wide bandwidth: 1 MHz; (4)no phase reversal; (5)low input currents: 4 pA; (6)unity gain stable; (7)rail-to-rail input and output.
The absolute maximum ratings of the AD8541ART-REEL7 can be summarized as:(1)Supply Voltage (VS): +6 V;(2)Input Voltage: GND to Vs;(3)Differential Input Voltage: +/-6 V;(4)Storage Temperature Range: -65 to +150 ;(5)Operating Temperature Range: -40 to +125 ;(6)Junction Temperature Range: -65 to +150 ;(7)Lead Temperature Range (Soldering, 60 sec): 300 . If you want to know more information about it, please download the datasheet in www.seekic.com or www.chinaicmart.com .
Parameters: | Technical/Catalog Information | AD8541ART-REEL7 |
| Vendor | Analog Devices Inc (VA) |
| Category | Integrated Circuits (ICs) |
| Packaging | Cut Tape (CT) |
| Amplifier Type | General Purpose |
| Number of Circuits | 1 - Single |
| Package / Case | SOT-23-5 |
| Slew Rate | 0.92 V/s |
| Gain Bandwidth Product | 1MHz |
| Current - Supply | 45A |
| Current - Output / Channel | 30mA |
| Voltage - Supply, Single/Dual (±) | 2.7 V ~ 5.5 V |
| Output Type | Rail-to-Rail |
| -3db Bandwidth | - |
| Current - Input Bias | 4pA |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Input Offset | 1000V |
| Drawing Number | * |
| Lead Free Status | Contains Lead |
| RoHS Status | RoHS Non-Compliant |
| Other Names | AD8541ART REEL7
AD8541ARTREEL7
AD8541ART REEL7CT ND
AD8541ARTREEL7CTND
AD8541ART-REEL7CT
|
