AD9520-5 Product Image

AD9 Series Datasheet download

Five Points

Part Number: AD9520-5



MFG: ADI



D/C: 09

Description: The AD9520-51 provides a multioutput clock distributionfunction with subpicosecond jitter performance, along with an on-chip PL...


Urgent Purchase

AD9520-5 General Description


The AD9520-51 provides a multioutput clock distributionfunction with subpicosecond jitter performance, along with an on-chip PLL that can be used with an external VCO.

The AD9520

AD9520-5 Maximum Ratings

Primary Clock Function Generation
On-Chip Multiplier PLL Core
+Supply Voltage (V) 3.3V
Max Input Frequency 250MHz
# of Outputs 12
Max f-out (MHz) 2400MHz
I/O Interface Serial
Package 64-LFCSP
Output Logic CMOS,LVDS,LVPECL
Product Description Multi-Output Clock Generator

AD9520-5 Connection Diagram

AD9520-5 Connection Diagram
