ADC20461CIWM

The ADC20461CIWM is one member of the ADC20461 family which is designed as the 10-bit 600 ns A/D converter with input multiplexer and sample/hold that can be used in (1)digital signal processor front ends; (2)instrumentation; (3)disk drives; (4)mobile telecommunications. And the key specifications of this device are:(1)conversion time to 10 bits 600 ns typical; (2)sampling rate 800 kHz; (3)low power dissipation 235 mW (max); (4)total harmonic distortion (50 kHz) .60 dB (max); (5)no missing codes over temperature.

Features of the ADC20461CIWM are:(1)built-in sample-and-hold; (2)single +5V supply; (3)1, 2, or 4-input multiplexer options; (4)no external clock required; (5)speed adjust pin for faster conversions. The absolute maximum ratings of the ADC20461CIWM can be summarized as:(1)supply voltage (V+=AVCC= DVCC):-0.3V to +6V;(2)voltage at any input or output:-0.3V to V+ +0.3V;(3)input current at any pin:5 mA;(4)package input current:20 mA;(5)power dissipation:875 mW;(6)ESD susceptability:2000 V;(7)soldering information N package (10 sec):260°C;(8)junction temperature:150°C;(9)storage temperature range:-65°C to +150°C. If you want to know more information such as the electrical characteristics about the ADC20461CIWM, please download the datasheet in www.seekic.com or www.chinaicmart.com.
