ADSP-2186BST-133

The ADSP-2186BST-133 is a single-chip microcomputer optimized for digital signal processing (DSP) and other high speed numeric processing applications. The features of ADSP-2186BST-133 are: (1)25 ns Instruction Cycle Time 40 MIPS Sustained Performance; (2)Single-Cycle Instruction Execution; (3)Single-Cycle Context Switch; (4)3-Bus Architecture Allows Dual Operand Fetches in Every Instruction Cycle; (5)Multifunction Instructions.

The following is about the absolute maximum ratings of ADSP-2186BST-133: (1)VDD: 4.5V min and  5.5 V max; (2)TAMB: 0 to +70°C.

The electrical characteristics of the ADSP-2186BST-133 are: (1)Hi-Level Input Voltage: 2.0 V @ VDD = max; (2)Hi-Level CLKIN Voltage: 2.2 V @ VDD = max; (3)Lo-Level Input Voltage: 0.8 V @ VDD = min; (4)Hi-Level Output Voltage: 2.4V @ VDD = min, IOH = 0.5 mA; (5)Hi-Level Input Current: 10mA @ VDD = max, VIN = VDD max; (6)Lo-Level Input Current: 10mA @ VDD = max, VIN = 0 V; (7)Three-State Leakage Current: 10mA @ VDD = max, VIN = VDDmax.
